Acer Aspire 1430/1830/1830T schematic, JV10-CS

The motherboard schematic for Acer Aspire 1430, Acer Aspire 1830, Acer Aspire 1830T laptop/notebook, Wistron JV10-CS.
CPU: Intel SFF
Chipset: Intel PCH
OEM: Wistron Corporation
Project code:91.4GS01.001
PCB P/N:48.4GS01.0SA
REVISION:09918-1
Document Number: JV10-CS
Rev: -1
Format: PDF
Total Pages: 50
Sale Price: 12.5$

Acer Aspire 1430 1830 1830T Block Diagram:
