Acer Aspire 4740/4740G/4745/5740/5745 schematic, NALG0 LA-5681P

The motherboard schematic for Acer Aspire 4740, Acer Aspire 4740G, Acer Aspire 4745, Acer Aspire 5740, Acer Aspire 5745 laptop/notebook, NALG0 M/B Compal LA-5681P, NAL90/NALG0 M/B Schematics Document.
CPU: Intel Auburndale (UMA/DIS)/ Clarksfield (DIS) + Nvidia N11MGE1
Chipset: Intel Ibex Peak-M
OEM: Compal Electronics, Inc.
Model Name : NALG0
File Name: LA5681P
Document Number: NALG0 M/B LA-5681P Schematic
Revision: 1.0
Total Pages: 60
Sale Price: 11.5$

Acer AS4740 4745 5740 5745 Block Diagram:

Acer AS4740 4745 5740 5745 Block Diagram
