Acer Aspire 7540 7540G schematic, JV71-TR

The motherboard schematic for Acer Aspire 7540, Acer Aspire 7540G laptop/notebook, Wistron JV71-TR.
CPU: AMD Caspian S1g3
North Bridge: AMD RS880M
South Bridge: AMD SB710
OEM: Wistron Corporation
Project code: 91.4FP01.001
PCB P/N : 48.4FP02.0SB
REVISION: 09243-SB
Document Number: JV71-TR
Rev: SB
Format: PDF
Total Pages: 61
Sale Price: 11.5$

Acer Aspire 7540 7540G Block Diagram:

Acer Aspire 7540 7540G Block Diagram
