Acer eMachines G420 G520 G620 G720 schematic(ZY5D)

The motherboard schematic for acer eMachines G420, eMachines G520, eMachines G620, eMachines G720 laptop/notebook, Quanta ZY5/ ZY5D.
CPU: AMD Griffin S1G2
Chipset: MCP77M
OEM: Quanta Computer Inc.
PROJECT: ZY5D
Rev: 3B
Format: PDF
Total Pages: 35
File size: 1.03MB
Language: English
Sale Price: 12.5$

Acer eMachines G420 G520 G620 G720 Block Diagram:

Acer eMachines G420 G520 G620 G720 Block Diagram
