Dell Inspiron 1501 schematic(Quanta_FX2)

The motherboard schematic diagram for DELL Inspiron 1501 laptop/notebook.
CUP: AMD S1 Turion 64 Rev.F Dual-Core/Sempron Rev.F Single-Core
Chip Set: RS485 A12 & SB600 A13
OEM: QUANTA
Title: Kirin (FX2 with NS)
Document Number: FX2
VER: 1A
Format: PDF
Total Pages: 45
File size: 964KB
Language: English
Sale Price: 12.5$

Dell Inspiron 1501 Block Diagram:

Dell Inspiron 1501 Block Diagram
