Dell Inspiron 17R N7110 (Discrete) schematic, Quanta R03A/V03A

The motherboard schematic for Dell Inspiron 17R Dell Inspiron N7110 laptop/notebook, Quanta R03A/V03A Mainboard.
CPU: Sandy Bridge 45W
Discrete VGA Nvidia N12P-GE (128bit)
Chipset: Mobile Intel Series 6 Chipset PCH Couger Point HM67
OEM: Quanta Computer Inc.
Document Number: R03A/V03A
Rev: 1A
Format: PDF
Total Pages: 50
File size: 2.18MB
Sale Price: 11.5$

Dell Inspiron 17R N7110 (Discrete) Block Diagram:
