Dell Inspiron M301Z schematic, Dell Inspiron Z INTEL

The motherboard schematic for Dell Inspiron M301Z INTEL laptop/notebook, Inspiron Z — INTEL.
CPU: Dual Core Intel Arrandale
Discrete GPU ATI Park LP-S3
Chipset: Intel Ibex Peak M
OEM: Dell/ Flex Confidential
Document Number: Inspiron Z — INTEL
Rev: X01
Format: PDF
Total Pages: 57
File size: 1.56MB
Sale Price: 11.5$

Dell Inspiron M301Z Block Diagram:
