Dell Latitude 13 3380 16824-1 Schematic & Boardview

The Schematic (*.pdf), Boardview (*.brd Allegro), Boardview (*.cad), Boardview (*.pdf), BOM file (.xlsx / list of componets) for Dell Latitude 13 3380, 16824-1 Motherboard.

CPU/PCH: Intel SkyLake/KabyLake-U DDR4
GPU: UMA
EC/KBC: MEC1415-NU-GP
Format: pdf, cad, brd, xlsx
Searchable PDF file, No watermark of website
Language: English
Sale Price: 16.5$

Also included:
— BoardView file (.pdf, .cad, .brd)
— BOM file (.xlsx / list of componets)
— Power Block Diagram
— Power Sequence Step-by-Step Block diagram
— Power Sequence Timing Diagram
— PCH/KBC SMBUS Block Diagram
— Clock Block Diagram
— Thermal Block Diagram
— Audio Block Diagram

File list:
16824-1.1125WZS1633.brd.7z
16824.pdf
Dell Latitude 3380 Wistron Keystone 13 WIN 16824-1 BoardView.cad
16824-1 BOTTOM.pdf
16824-1 TOP.pdf
Keystone13Win_COSBOM_A00_20161201.xlsx

Boardview Software (Download)

  • Open Boardview(.brd) file with Allegro Free Physical Viewer
  • Open Boardview(.cad) file with BoardViewer

16824

Dell Latitude 13 3380 16824-1 Schematic & Boardview

Dell Latitude 13 3380 16824-1 Schematic & Boardview

Dell Latitude 3380 Wistron Keystone 13 WIN 16824-1 BoardView(.cad)
