Dell Latitude E6410 (Discrete) schematic, NCL01 LA-5472P

The schematic diagram for Dell Latitude E6410 (Discrete) notebook/laptop, NCL01 Mainboard, Compal LA-5472P.
CPU: Arrandale 4MB (Socket G1)
Chipset: INTEL IBEXPEAK-M
OEM: Compal Electronics, Inc.
MODEL NAME : NCL01
PCB NO : LA-5472P ( DAA00001I00)
Document Number: LA-5472P
Rev: A00
Format: PDF
Total Pages: 66
File size: 2.00MB
Sale Price: 11.5$

Dell Latitude E6410 (Discrete) Block Diagram:
