Fujitsu Siemens Amilo M1451G schematic, M50EA0

The motherboard schematic for Fujitsu Siemens Amilo M1451G laptop/notebook, UNIWILL M50EA0.
CPU: Dothan
North Bridge: INTEL 915PM + ATI M22
South Bridge: INTEL ICH6-M
OEM: UNIWILL COMPUTER CORP.
Model : M50EA0
Document Nunber: 3145
Format: PDF
Sale Price: 8.5$

Fujitsu Siemens Amilo M1451G Block Diagram:
