HP Pavilion dv4/Compaq CQ40 schematic, NBW20 LA-4117P

The motherboard schematic for HP Pavilion dv4, Compaq Presario CQ40 laptop/notebook, Mobile AMD S1G3 CPU with ATI RS880M(NB) & SB710(SB) core logic, Consumer AMD 14″ UMA – Ripley 2.0 (NBW20).
CPU: AMD S1G3
North Bridge: ATI RS880M
South Bridge: ATI SB710
OEM: Compal Electronics, Inc.
Document Number: LA-4117P
Revision: 0.3
Format: PDF
Total Pages: 56
File size: 1.20MB
Sale Price: 10.5$

HP Pavilion dv4 Compaq CQ40 Block Diagram:
