HP Pavilion DV7 schematic,H710DI1,HPMH-40GAB6600-B130

The motherboard schematic for HP Pavilion DV7 laptop/notebook, Flex H710DI1 Mainboard.
CPU: Intel Sandy Bridge 32nm SV PGA988B i3, i5 DC 35W/ i7 QC 45W
GPU AMD 15.6”/17.3” Muxless Hybrid: Whistler XT 128bit 35W + gDDR5 x8
Chipset: Cougar Point M
OEM: Flex Computing
Project Name: H710DI1
Document Number: HPMH-40GAB6600-B130
Rev: A
Format: PDF
Total Pages: 63
File size: 1.47MB
Sale Price: 11.5$

HP Pavilion DV7 Block Diagram:
