Lenovo 3000 G555 schematic, NAWA2 LA-5972P

The motherboard schematic for Lenovo 3000 G555 laptop/notebook, NAWA2 Compal LA-5972P.
CPU: AMD S1G3
North Bridge: ATI RS880M + ATI PARK-S3 & M93-S3
South Bridge: ATI SB710
OEM: Compal Electronics, Inc.
Model Name : NAWA1
Document Number: LA-5972P
Revision: 1.0
Format: PDF
Total Pages: 49
File size: 1.39MB
Sale Price: 10.5$

Lenovo 3000 G555 Block Diagram:
