Lenovo IdeaPad B570/Z570/V570 schematic, 10290 LZ57

The motherboard schematic for Lenovo IdeaPad B570, Lenovo IdeaPad Z570, Lenovo IdeaPad V570 notebook/laptop, Wistron LZ57 Mainboard, Discrete/UMA Schematics Document.
CPU: Intel Sandy Bridge
Discrete VGA NVIDIA N12P-GE/GV
Chipset: Intel PCH Cougar Point
OEM: Wistron Corporation
Project code : 91.4PA01.001
PCB P/N : 10290
Revision : -SC
Document Number: LZ57
Revision: -1
Format: PDF
Total Pages: 102
File size: 1.93MB
Sale Price: 11.5$

Lenovo IdeaPad B570 Z570 V570 Block Diagram:
