Lenovo IdeaPad Y460C schematic, Quanta KL2B

The motherbord schematic for Lenovo IdeaPad Y460C notebook/laptop, Quanta KL2B, KL2B Intel Calpella Platform with Optimus GFX.
CPU: Auburndale (UMA+VGA) /Clarksfield (VGA)
Discrete VGA nVidia N11P-GE1 (40nm)
Chipset: Ibex Peak-M
OEM: Quanta Computer Inc.
Project: KL2A NOTE Calpella DIS
Rev: 1A
Format: PDF
Total Pages: 46
File size: 1.43MB
Sale Price: 10.5$


Lenovo IdeaPad Y460C Block Diagram:
Lenovo IdeaPad Y460C Block Diagram

Lenovo IdeaPad Y460C Block Diagram
