Lenovo ThinkPad Edge E540 schematic, NM-A161

The motherboard schematic for Lenovo ThinkPad Edge E540 laptop/notebook, E540 NM-A161 Rev1.0 Schematic. Intel Haswell Processor with DDRIII + Lynx point PCH, nVIDIA N14P-GV2/ N14M-GL
CPU: Intel Haswell Processor with DDRIII
Chipset: Intel PCH
OEM: LCFC.
Document Number: E540 NM-A161
Format: PDF
Total Pages: 57
File list:

  • AILE2 NM-A161 r10 Lenovo ThinkPad Edge E540.pdf
  • AILE2 NM-A161 r01 Lenovo ThinkPad Edge E540.pdf

Sale Price: 10.5$


ThinkPad Edge E540 Block Diagram:
thinkpad-edge-e540-block-diagram
