Lenovo Thinkpad SL410 schematic, Discrete GC2

The motherboard schematic for Lenovo Thinkpad SL410 (Discrete) notebook/laptop, Quanta G-Note Montevina Mainboard, G-Note Montevina Discrete.
CPU: Penryn
North Bridge: Cantiga + AMD M92-S2 XT
South Bridge: ICH-9M
OEM: Quanta Computer Inc.
Project: G-Note Montevina
Rev: 2A
Format: PDF
Total Pages: 55
Sale Price: 12.5$

Thinkpad SL410 Block Diagram:

Thinkpad SL410 Block Diagram
