Lenovo ThinkPad T510/W510 (Discrete) schematic, 08271-SC

The motherboard schematic for Lenovo ThinkPad T510,Lenovo ThinkPad W510 laptop/notebook, Wistron Kendo-1 WS Mainboard
CPU: Intel Clarksfield (QC)
Discrete VGA NVIDIA N10P-GLM
Chipset: Intel PCH
OEM: Wistron Corporation
Project code : 91.4CU01.001
PCB (Raw Card) : 08271-SC
Document Number: Kendo-1 WS
Rev: SC
Format: PDF
Total Pages: 109
Sale Price: 16.5$

ThinkPad T510/W510 Block Diagram:

ThinkPad T510 W510 Block Diagram
