Toshiba Satellite A300D/A350D/A355D schematic, KTKAE LA-4581P

The motherboard schematic for Toshiba Satellite A300D, Toshiba Satellite A350D, Toshiba Satellite A355D notebook/laptop, KTKAE Mainboard Compal LA-4581P.
CPU: AMD S1G2
North Bridge: ATI RS780M/RS780MC/RX781 + ATI M82/86 with VRAM
South Bridge: ATI SB700
OEM: Compal Electronics, Inc.
Model Name: KTKAE
File Name: LA-4581P
Document Number: LA-4581P
Rev: 1.0
Format: PDF
Total Pages: 45
File size: 952KB
Sale Price: 9.5$

Toshiba Satellite A300D/A350D/A355D Block Diagram:
