Toshiba Satellite C850/C855 schematic,CPU 35W,DAKAR10F/FG/R/RG

The motherboard schematic for Toshiba Satellite C850, Toshiba Satellite C855 laptop/notebook, Inventec DAKAR10F/FG/R/RG Mainboard, 6050a2491301.
CPU: IVY BRIDGE/SANDY BRIDGE (35W)
Discrete VGA AMD W/ POWER EXPRESS THAMES LE THAMES XT SEYMOUR XTX
Chipset: PCH PANTHER POINT COUGAR POINT
OEM: Inventec.
TITLE:
DOC.NUMBER: 1310xxxxx-0-0
Rev: X01
Format: PDF
Total Pages: 69
File size: 4.42MB
Sale Price: 11.5$

Toshiba Satellite C850 C855 Block Diagram:
