Acer Aspire 5750 Schematic, Compal LA-6902P JE50-HR SJV50-HR

The motherboard schematic diagram for Acer Aspire 5750 Laptop, JE50-HR/SJV50-HR(P5WE0/P5WS0) M/B Schematics Document, Intel Sandy Bridge Processor with DDRIII + Cougar Point PCH, Nvidia N12P GS/GV.
CPU: Intel Sandy Bridge
Chipset: Intel Cougar Point PCH
Model Name: JE50-HR/SJV50-HR
Compal Project Name: P5WE0/P5WS0
File Name: LA-6902P
Document Number: JE50-HR/SJV50-HR M/B Schematics
OEM: Compal
REV: 0.1
Format: PDF
Total Pages: 61
File size: 1.7MB
Sale Price: $9.5

Acer Aspire 5750 Block Diagram:
Acer Aspire 5750 Block Diagram

Acer Aspire 5750 Block Diagram
