acer Aspire 7741/7741Z/7741G/7741ZG, 48.4HN01.0SD, JE70-CP

The motherboard schematic for Acer Aspire 7741, Acer Aspire 7741Z, Acer Aspire 7741G, Acer Aspire 7741ZG laptop/notebook, Wistron JE70-CP
CPU: Intel Arrandale Clarksfield
Chipset: INTEL PCH
OEM: Wistron Corporation
Project code: 91.4HN01.001
PCB P/N: 48.4HN01.0SD
REVISION: 09923-1M
Document Number: JE70-CP
Rev: -1M
Format: PDF
Total Pages: 67
File size: 1.35MB
Sale Price: 11.5$


acer Aspire 7741 Block Diagram:
acer Aspire 7741 Block Diagram

acer Aspire 7741 Block Diagram
