acer TravelMate 4260 4262 schematic(Discrete)

The motherboard schematic diagram for acer TravelMate 4260, acer TravelMate 4262 laptop/notebook, HBL50 Compal LA-2921P. Intel Yonah Processor with 945GM/945PM + DDRII + ICH7M, with nVIDIA G73M/72MV.
CPU: Yonah
North Bridge: Intel 945PM/GM
South Bridge: Intel ICH7-M
OEM: Compal Electronics, Inc.
File Name: LA-2921P
Model Name: HBL50
Document Number: HBL50 LA-2921P
Revision: 0.3
Format: PDF
Total Pages: 59
File size: 1.34MB
Language: English
Sale Price: 9.5$


acer TravelMate 4260 4262 Block Diagram(Discrete):

acer TravelMate 4260 4262 Block Diagram(Discrete)

acer TravelMate 4260 4262 Block Diagram(Discrete)
