Dell Inspiron 3493 3593 3793 5493 5593 3595 Schematic & Boardview FDI52 LA-H872P

Schematic (*.pdf), Boardview (*.brd Allegro), Boardview (*.pdf), Boardview (*.cad), BOM file (.xls / list of componets) for Dell Inspiron 3493, Dell Inspiron 3593, Dell Inspiron 3793, Dell Inspiron 5493, Dell Inspiron 5593, Dell Inspiron 3595, Dell Inspiron 15 3595 laptop.
AMD Stoney Ridge
OEM: Compal FDI52 LA-H872P
Rev: 1.00 (A00)
PCB NO: DA60026R000
PROJECT NAME: LA-H872P
Format: PDF, BRD, CAD, XLS
Searchable PDF file, No watermark of website
Sale Price: 16.5$

File list:
LA-H872P_R10-0606.brd.7z
DellBOM_Template_LOKI_N3_MLK_STR_20190614_V01.xls
LA-H872P Boardview (.CAD).cad
LA-H872P BOTTOM.pdf
LA-H872P TOP.pdf
LA-H872P_R10_15w_20190605b_dell.pdf

Boardview Software (Download)

• Open Boardview(.brd) file with Allegro Free Physical Viewer
• Open Boardview(.cad) file with BoardViewer
