Dell Inspiron N4010 (UMA) schematic, Quanta UM8

The motherboard schematic for Dell Inspiron N4010 laptop/notebook, UM8 Mainboard, Quanta UM8 UMA.
CPU: INTEL Arrandale
Chipset: INTEL PCH Ibex Peak-M
OEM: Quanta Computer Inc.
PROJECT: UM8 UMA
Revision : 1A
Format: PDF
Total Pages: 46
Sale Price: 11.5$

Dell Inspiron N4010 (UMA) Block Diagram:
