Lenovo ThinkPad Edge E10 (Intel) schematic, Quanta FL6 MK2-Intel

The motherboard schematic for Lenovo ThinkPad Edge E10 (Intel) laptop/notebook, Quanta FL6 MK2-Intel.
CPU: Arrandale CPU
Chipset: PCH Ibex Peak-M Intel(R) 5 Series Express Chipset
OEM: Quanta Computer Inc.
Project: MK2-Intel
Rev: 1C
Format: PDF
Total Pages: 42
File size: 1.13MB
Sale Price: 10.5$

ThinkPad Edge E10 (Intel) Block Diagram:
