Toshiba Satellite P35 laptop schematic diagram(LA-2371)

The document is PDF format, include:
The motherboard schematic diagram for Toshiba Satellite P35 laptop/notebook, LA-2371 REV 1.0 Schematic. Portability Prescott/Northwood, RC300ML(RX300ML)+IXP150+ATI M11P(128MB VRAM).
CUP: Northwood-MT Prescott-MT
Chip Set: ATI-RC300ML(ATI-RX300ML) & ATI-IXP150
OEM: Compal Electronics, Inc.
File Name: LA-2371
Model Name: EFQ00 & EEQ00
File Name: LA-2371 Rev: 1.0
Format: PDF
Total Pages: 56
File size: 1.18MB
Language: English
Sale Price: 12.5$

Toshiba P35 Block Diagram:

Toshiba P35 Block Diagram
