Toshiba Satellite A500 schematic,NSKAA LA-5361P

The schematic diagram for Toshiba Satellite A500 laptop/notebook, NSKAA Mainboard Compal LA-5361P
CPU: Mobile Arrandale
VGA MXM/B : ATI M92XT,64bit with 256M/512MB ; ATI M96,128bit with 512M/1G
Chipset: Intel Ibex Peak M
OEM: Compal Electronics, Inc.
Model name: NSKAA
File name: LA-5361P
Title: SCHEMATIC,MB A5361
Document Number: 401715
Rev: B
Format: PDF
Total Pages: 52
File size: 1.33MB
Sale Price: 10.5$


Toshiba Satellite A500 Block Diagram:
Toshiba Satellite A500 Block Diagram
