Toshiba Satellite X200 X205 P200 P205schematic(LA-3441P)

The document is PDF format, the motherboard schematic for Toshiba Satellite X200, Toshiba Satellite X205 notebook/laptop, also fit Toshiba Satellite P200, Toshiba Satellite P205, Compal ISRAA LA-3441P. Mobile Merom uFCPGA with Intel
Crestline_PM+ICH8-M core logic.
CPU: Mobile Merom
North Bridge: Intel Crestline
South Bridge: Intel ICH8-M
OEM: Compal
Document Number: ISRAA LA-3441P
Revison: 0.1
Format: PDF
Total Pages: 48
File size: 1.33MB
Language: English
Sale Price: 12.5$

Toshiba Satellite X200 X205 Block Diagram:
