Dell Vostro 5368 5468 Inspiron 7569 7778 schematic diagram, Compal LA-D822P
The motherboard schematic for Dell Vostro 5368, Dell Vostro 5468, Dell Inspiron 7569, Dell Inspiron 7778 laptop/notebook, Compal LA-D822P. Dali & Astro BKA40/BKA50/BKD40/BKD50 MB Schematic Document.
PCB 1G7 LA-D822P REV0 M/B UMA, DA80017E000.
CPU: Skylake – U / Kabylake – U
Memory Bus DDR4 1866/2133MHz Dual Channel
OEM: Compal Electronics, Inc.
PCB NO: LA-D822P
DA80017E000
Total sheet: 46
Sale Price: 12.5$
Block Diagram:
Dell Vostro 5368 5468 Block Diagram
