Lenovo IdeaPad Y460 (SandyBridge) schematic, KL2A KL2D

The motherbord schematic for Lenovo IdeaPad Y460 notebook/laptop, KL2A Intel Huron River Platform with Discrete GFX, Quanta KL2A/KL2D.
CPU: SandyBridge 0.61+ AMD Capilano
Chipset: CougarPoint 0.7 PCH
OEM: Quanta Computer Inc
Project: KL2D
Rev: 1A
Format: PDF
Total Pages: 47
File size: 1.50MB
Sale Price: 11.5$


Lenovo IdeaPad Y460 (SandyBridge) Block Diagram:
Lenovo IdeaPad Y460 Block Diagram

Lenovo IdeaPad Y460 Block Diagram
