Dell Inspiron N4020 schematic, DJ1 Montevina UMA, 09275-SA

The motherboard schematic for Dell Inspiron N4020 laptop/notebook, DJ1 Montevina UMA Schematics Document.
CPU: Intel Mobile Penryn
North Bridge: Intel GM45
South Bridge: Intel ICH9-M
OEM: Wistron Corporation
Project code : 91.4EK01.001
PCB P/N : 48.4EK06.0SA
Revision : 09275-SA
Document Number: DJ1 Montevina UMA
Rev: A00
Format: PDF
Total Pages: 88
File size: 1.23MB
Sale Price: 10.5$

Dell Inspiron N4020 Block Diagram:
