Acer Aspire One AO751 schematic, ZA3 Mainboard

The motherboard schematic for Acer Aspire One AO751 laptop/notebook, Quanta ZA3
CPU: Intel@Atom(Silverthorne) Z520/Z530
Chipset: Intel@ System Controller Hub (Poulsbo)
OEM: Quanta Computer Inc.
PROJECT: ZA3
Rev: 1A
Format: PDF
Total Pages: 35
File size: 851 KB
Sale Price: 12.5$

Acer Aspire One AO751 schematic Block Diagram:
