Acer Aspire One AOD150 netbook schematic, KAV10 LA-4781P

The motherboard schematic for Acer Aspire One D150 Netbook, KAV10 Mainboard, Compal LA-4781P,Intel Diamondville Processor with Calistoga(945GSE) + DDRII + ICH7M.
CPU: Diamondville SC
North Bridge: Calistoga GSE
South Bridge: ICH7M
OEM: Compal Electronics, Inc.
Model Name : KAV10
File Name : LA-4781P
P/N : DA60000A600(R0)
DA60000A610(R1)
DAZ06F00100
Document Number: KAV10 LA-4781P
Format: PDF
Total Pages: 40
File size: 1.05MB
Language: English
Sale Price: 12.5$

Acer Aspire One AOD150 Block Diagram:
