DELL Inspiron Mini 10 schematic, KIU10 LA-4761P

The motherboard schematic for Dell Inspiron Mini 10 (KIU10-Tiger) laptop, KIU10 Mainboard, Compal LA-4761P M/B Schematics Document.
CPU: CPU-Silverthrone 1.33G/1.6G
Chipset: SCH- Poulsbo
OEM: Compal Electronics, Inc.
Model Name : Kxxxxx
Tiger System-Board
File Name: Tiger Main-Board
Document Number: KIU10 LA4761P
Revision: 1.0
Format: PDF
Total Pages: 22
Sale Price: 9.5$

DELL Inspiron Mini 10 Block Diagram:
