Fujitsu Siemens Amilo Pi 2512 schematic & Service Manual, L53II0

The motherboard schematic for Fujitsu Siemens Amilo Pi 2512 laptop/notebook, L53IIx MainBoard.
CPU: Merom
North Bridge: INTEL Crestline
South Bridge: INTEL ICH8-M
OEM: UNIWILL COMPUTER CORP.
Model: L53II0
PCB P/N: 37GL53010-A1
PCBA
P/N: 82GL53010-A1
Revision : A1
Format: PDF
Total Pages: 34
Sale Price: 9.5$

Fujitsu Siemens Amilo Pi 2512 Block Diagram:
