Fujitsu Siemens Esprimo Mobile U9200 schematic

The schematic diagram for Fujitsu Siemens Esprimo Mobile U9200 laptop/notebook, Wistron S11D.
CPU: Merom
North Bridge: Crestline GM 965GM/GML
South Bridge: ICH8M
OEM: Inventec Corporation
Title: S11D (Merom+Crestline+ICH8M)
Rev: 0.3
Format: PDF
Total Pages: 43
File size: 1.04MB
Sale Price: 9.5$

Fujitsu Siemens U9200 Block Diagram:
