Lenovo E280 E280S schematic, Quanta LE1

The motherbord schematic for Lenovo E280 E280S (LE1) notebook/laptop.
CPU: INTEL CPU Celeron/ Prescott (SOCKET-479)
North Bridge: SiS 661FX
South Bridge: SiS 963
OEM: Quanta
Project: LE1
Rev: 1A
Format: PDF
Total Pages: 27
Sale Price: 9.5$

Lenovo E280 E280S Block Diagram:
