Lenovo ThinkPad X230 schematic, LDB-2 Dasher-2

The motherboard schematic Lenovo ThinkPad X230 notebook/laptop, Wistron Dasher-2 Mainboard.
CPU: Intel Ivy Bridge
Chipset: Intel Panther Point
OEM: Wistron Corporation
LDB-2 91.4RA01.001
Document Number: Dasher-2
Rev: -1
Format: PDF
Total Pages: 101
File size: 2.90MB
Sale Price: 11.5$


Lenovo ThinkPad X230 Block Diagram:
Lenovo ThinkPad X230 Block Diagram

Lenovo ThinkPad X230 Block Diagram
