Sony V030 MP schematic, Sony MBX-237 schematic

The motherboard schematic for Sony V030 MBX-237 Main Board, Sony VPC-SD, VPC-SC , VPC-SB , VPC-SA series.
CPU: Sandy Bridge-DC (SNB) Processor (35W)
dGPU ATI Seymour XTX 512 MB (1Gb x 4) Whistler LP 1GB/2GB (1Gbx8/2Gbx8)
Chipset: PCH Intel Cougar Point
OEM: Foxconn
Document Number: V030 MP MB
Rev: 1.3
Format: PDF
Total Pages: 75
File size: 2.68MB
Sale Price: 11.5$


Sony V030 MP Block Diagram:
Sony V030 MP Block Diagram

Sony V030 MP Block Diagram
