Sony Vaio VPC-L Series schematic, M920 MBX-209

The motherboard schematic for Sony Vaio VPC-L Series: VPC-L137FX, VPC-L11M1E… , M920 MBX-209 Main Board.
CPU: Dual/Quad Core (uSFF)
North Bridge: Eaglelake + N10P-GS+1GB DDR3 or N10M-GS+512MB DDR3
South Bridge: ICH10
OEM: Foxconn
Document Number: M920 PVT
Rev: 0.4
Format: PDF
Total Pages: 93
File size: 1.25MB
Sale Price: 10.5$

Sony Vaio VPC-L Series Block Diagram:
