Sony VGN-CR21S/PCG-5J5M schematic, QUANTA GD1A

The motherboard schematic diagram for Sony GD1A Mainboard, for Sony VGN-CR21S, Sony PCG-5J5M…Quanta QD1A
CPU: MEROM
North Bridge: Crestline + ATI M64
South Bridge: ICH8-M
OEM: QUANTA COMPUTER
Document Number: GD1A Main Board
Rev: 2A
Format: PDF
Total Pages: 35
Sale Price: 12.5$


Sony VGN-CR21S/PCG-5J5M Block Diagram:

Sony VGN-CR21S PCG-5J5M Block Diagram

Sony VGN-CR21S PCG-5J5M Block Diagram
