Toshiba Satellite M50, M55, Tecra A5 schematic, ECU00,LA-2721

The motherboard schematic for Toshiba Satellite M50, Satellite M55, Toshiba Tecra A5 laptop/notebook, LA-2721 Schematics Document, Intel Dothan / Alviso GM(PM) / DDR-1 / ICH6-M (nVIDIA NV44MV / ATi M24C).
CPU: Intel Dothan
North Bridge: Intel Alviso GM( GML,PM)
South Bridge: Intel ICH6-M
OEM: Compal Electronics, Inc.
Document Number: Boston LA-2721
File Name: LA-2721
Format: PDF
Include:
boston_la-2721_0406_bom.pdf
ecu00_ls2721_v03_0330b.pdf
ecu00_ls2722_vga-nv44_v03.pdf
ecu00_ls-2723_sw_v02_0224a.pdf
ecu00_ls-2725_crtlan_v03_0325a.pdf
Sale Price: 12.5$

Toshiba Satellite M50, M55, Tecra A5 Block Diagram:
