Dell Vostro 1500 1520 (Discrete) schematic & boardview, KML50 LA-4595P

The motherboard schematic and boardview(.brd) for Dell Vostro 1500, Dell Vostro 1520 laptop, KML50 Mainboard, Compal LA-4595P, Half Penny Bridge 15.4.
CPU: Penryn -4MB (Socket P)
North Bridge: Intel Cantiga MCH + nVIDIA NB9M-GS
South Bridge: Intel ICH9-M
OEM: Compal Electronics, Inc.
PCB NO: LA-4595PR04
BOM P/N: DA80000DR00
MODEL NAME: KML50 DIS
File Name: LA-4595P
Document Number: LA-4595P
Revision: 1.0
Format: PDF
Total Pages: 49
File size: 1.51MB
Sale Price: 11.5$ (include boardview)

Dell Vostro 1500 1520 Block Diagram:
