Lenovo Ideapad Y700-15ISK Y700-17ISK Schematic & Boardview, BY511/BY710 NM-A541

2021-02-19 Lenovo Schematics

The motherboard schematic diagram and Boardview (.TVW) for Lenovo Ideapad Y700-15ISK, Lenovo Ideapad Y700-17ISK laptop/notebook, BY511/BY710 M/B Schematics Document,Intel Skylake H-Processor with DDR4 + NV N16P-GX GPU, NM-A541 motherboard.
CPU Skylake H with DDR4
PCH Intel Skylake H
GPU nVIDIA N16P-GX (DIS)
EC ITE IT8371
Document Number: BY511/BY710
OEM: LCFC
Format: PDF, TVW
Searchable PDF file, No watermark of website
Language: English
Total Pages: 66
Sale Price: 12.5$ (include Boardview)
