Lenovo Yoga 510-14AST, IdeaPad 310S-14AST, IdeaPad 500-14ACZ Schematic BAUS0/Y0 LA-D541P

The Schematic (*.PDF) for Lenovo Yoga 510-14AST, Lenovo IdeaPad 310S-14AST, Lenovo IdeaPad 500-14ACZ laptop, Compal BAUS0/Y0 LA-D541P Motherboard.
Model: Lenovo Yoga 510-14AST, IdeaPad 310S-14AST, IdeaPad 500-14ACZ
Motherboard: Compal BAUS0/Y0 LA-D541P
CPU: AMD Stoney Ridge SOC with DDR4
GPU: AMD R16M-M1-30 (DIS) / (UMA)
EC: Nuvoton NPCE388NA1DX
File type: PDF (Searchable)
Language: English
Sale Price: 12.5$
