Lenovo Thinkpad T480S Schematic & Boardview, Kolar-1 NM-B471

The motherboard schematic & Boardview for Thinkpad T480S laptop/notebook, LCFC Kolar-1 NM-B471.
Project Name: Kolar-1
BOARD NO.: NM-B471
Format: PDF (include Boardview, page 98-99)
Pages: 99
OEM: LCFC
Sale Price: 13.5$

Lenovo Thinkpad T480S Schematic

Lenovo Thinkpad T480S Schematic

Thinkpad T480S Schematic

Thinkpad T480S Schematic
