Acer Aspire 9100 Series schematic diagram

The motherboard schematic diagram(pdf) for acer Aspire 9100 Series laptop/notebook. EDL70/71 Schematics Document, uFCBGA/uFCPGA Mobile Dothan Intel Alviso + ICH6M.

• 9101WLMi (LX.A5205.083)
• 9104WLMi (LX.A5205.030, LX.A5205.031, LX.A5205.036, LX.A5205.048, LX.A5205.060, LX.A5205.064, LX.A5205.068)
• 9112WLMi (LX.ACM05.050, LX.ACM05.084)
• 9113WLMi (LX.ACM05.091)
• 9114WLMi (LX.ACM05.080)

CUP: Pentium-M Dothan
North Bridge: INTEL Alviso
South Bridge: INTEL ICH6-M
OEM: Compal Electronics, Inc.
MODEL NAME: EDL70/71
Document Number: EDL71 LA-2351
Format: PDF
Total Pages: 59
File size: 1.25MB
Language: English
Sale Price: 7.5$

acer Aspire 9100 Block Diagram:
