Dell Latitude E6430 schematic, QAL81 LA-7782P

The motherboard schematic for Dell Latitude E6430 laptop/notebook, QAL81 Mainboard, Compal LA-7782P.
CPU: Ivy Bridge + DDR3
Discrete VGA Nvidia N13M
Chipset: Intel Panther Point-M
OEM: Compal Electronics, Inc.
Model Name : QAL81
PCB NO : LA-7782P (DAA00002J00)
Document Number: LA-7782P
Rev: 0.1
Format: PDF
Total Pages: 66
File size: 2.12MB
Sale Price: 11.5$


Dell Latitude E6430 Block Diagram:
Dell Latitude E6430 Block Diagram
