Fujitsu Siemens Amilo Si 3655 schematic, F30II0 Mainboard
The motherboard schematic for Fujitsu Siemens Amilo Si 3655 laptop/notebook, 13.3″ UMA, F30II0 M/B Circuit Diagram.
CPU: Intel PENRYN
North Bridge: CANTIGA
South Bridge: ICH9M
OEM: Elitegroup Computer Systems
Project : F30II0
Format: PDF
Total Pages: 36
2 PDF Files, include:
F30II0_B0_MB_DB_DDR2_0114_SIP.pdf (REV.B)
F30II0_C0F_MB_DB_DDR2_0605_SIP.pdf(REV.C0F)
Sale Price: 12.5$
Fujitsu Siemens Amilo Si 3655 Block Diagram:
Fujitsu Siemens Amilo Si 3655 Block Diagram
